Hyperion Distance Sensor for Hyperion 971IPS

Product Code: A900IPS-DIST-SENSOR

Our Distance Sensor fits to any feedback enabled 971IPS bar and is designed to automatically adjust the output frequency to match the target distance, decreasing the frequency if the target is far away and increasing it when the target is closer.

The Hyperion Distance Sensor is designed to work when the distance to the target is constantly changing, allowing the performance of the 971IPS to be optimised.

Please consult your local Meech Distributor for advice on this installation.

Download
Features & Benefits
Control of Mid and Long Range Bars

Option for any feedback enabled Hyperion 971IPS Pulsed DC Bar

Ultrasonic Distance Sensor

Clear distance measurement

Auto-detection of Sensor

No set-up of the integrated controller is required

Technical Characteristics
Dimensions (WxHxD)

75mm x 88mm x 65mm

Construction

ABS

Cable Length

Coiled 3000mm

Electrical Connection

3 pin M8 Connector

Weight

83g

Ambient Temperature

0 to 50 °C

Images
Documentation

Meech Hyperion Range Brochure

Download

Meech Static Control Brochure - English

Download

Hyperion Distance Sensor for Hyperion 971IPS

Product Code: A900IPS-DIST-SENSOR

Our Distance Sensor fits to any feedback enabled 971IPS bar and is designed to automatically adjust the output frequency to match the target distance, decreasing the frequency if the target is far away and increasing it when the target is closer.

The Hyperion Distance Sensor is designed to work when the distance to the target is constantly changing, allowing the performance of the 971IPS to be optimised.

Please consult your local Meech Distributor for advice on this installation.



Features & Benefits

Control of Mid and Long Range Bars Option for any feedback enabled Hyperion 971IPS Pulsed DC Bar
Ultrasonic Distance Sensor Clear distance measurement
Auto-detection of Sensor No set-up of the integrated controller is required

Technical Characteristics

Dimensions (WxHxD) 75mm x 88mm x 65mm
Construction ABS
Cable Length Coiled 3000mm
Electrical Connection 3 pin M8 Connector
Weight 83g
Ambient Temperature 0 to 50 °C
