251 Ion Gun
Product Code: 251
Meech’s Model 251 Ion Gun is a robust, lightweight injection moulded product for use with the Model 233v3 Pulsed DC Controller.
It is suitable for contamination blow-off and neutralisation of static charges in electronic applications and cleanroom environments. It is quick, easy and safe to use. Supplied with 2 metres of cable as standard.
DownloadTechnical Characteristics
0.16 kg
8 kV DC nominal (Model 233v3)
Machined titanium (replaceable)
190 mm
Not to be used above 7 bar (100 psi)
Recommended pressure 1.5 – 4 bar
(20 – 60 psi)
FR ABS
Less than 0.01 ppm
+/- 10 V at set up
72 dBA at 1.5 bar (20 psi)
Typically less than 0.5 secs
