904 Power Supply

Product Code: 904

The Meech Model 904 is a constant voltage AC power supply, designed to provide a 7kV source for Meech AC ionising equipment. It is adjustable to operate at 100-120v or 200-240v input voltages and is available in either 50Hz and 60Hz versions to suit local conditions.

The 904 utilises a modified shape of output wave form for powerful static neutralisation and is uniquely designed to allow automated manufacture for increased reliability and extended product life. The 904 incorporates a low voltage jack socket for connection of the Model 900vs2.

  Download
Features & Benefits
Automated manufacture on purposebuiltplant

Consistent, uniform winding gives more
robust and stable performance

Modified output wave form

More powerful static neutralisation, lower electrical stress and increased reliability

Illuminated indicator for high voltageoutput

Confirmation that the system is operational.
Can also assist in ionising system diagnosis

Connection ports for four ionising appliances and high load capacity

Several ionising appliances can be supplied by the same single power source

Short circuit current of

Ensures high level of operator safety

Mains voltage selector switch

Easy selection of appropriate mains voltage

IEC fused mains connector

Enables fast and easy connection to mains supply and reduced installation time

CUL and CE approved

Full conformance to international standards
(UL, CSA, CENELEC & CE)

Technical Characteristics
Weight

3.4Kg

Input Voltage

110 or 240V AC

Input Frequency

50Hz (904-50) or 60Hz (904-60)

Dimensions

145mm x 130mm x 113mm

Output current

< 5mA

Maximum load

Equivalent to 12 metres of ionising appliances and cable

Output

7.0kV

Power consumption

140W

Certifications

CE, UL.

Images
Documentation

Meech Static Control Brochure - English

Download

904 Operating Manual

Download

904_Assembly

Download
