971 Pulsed DC Bar

Product Code: 971

The 971 Pulsed DC bar delivers powerful, long range ionisation to control static electricity on a wide range of printing, converting and process machinery.

Using reliable Pulsed DC technology, the 971 delivers industry leading ionisation performance. Its great long range ability makes it ideal for use on applications such as rewinds and collection bins. In most installations, complete static control can be achieved without the need for air assistance. For more demanding applications, the integrated air-boost can be used to increase its capability at distance.  Meech’s ever reliable titanium emitter system gives extra-long service life. Resistive coupling makes the bar shockless to touch and safe for operators to handle. The design has been optimised to reduce the effects of contamination and to allow easy maintenance.

Download
Features & Benefits
Powerful long range Ionisation

Excellent static control on modern, fast machinery

Rigid profile

Minimises the number of mounting points required

Resistive coupling

Safe for operators to handle

Titanium emitter pins

Continue to give good ionisation after years of use

Replaceable emitter assemblies

Allows periodic replacement to extend service life

'T' slot mountings

Provides complete flexibilty of mounting points

Integrated air-boost

Increased perfomance for demanding applications

Technical Characteristics
Dimensions (cross section)

63mm x 72mm

Maximum length

3900mm

Weight

1.2 kg/metre

Construction

ABS Plastic FR

Mounting

‘T’ Slot with M4 x 20 studs

Cable length

2000mm HT in flexible plastic conduit, longer available.

Emitters

Sharp titanium pins

Power source

977v3 or 977CM

Input voltage

Up to 15KV

Output frequency

1Hz – 20Hz

Air-boost connection

6mm push-fit

Air consumption

5 cfm per 1000mm at 1 bar

Typical Operating Range

150 – 750mm
