Hyperion 971IPS-30 Extra Long-Range Pulsed DC Ionising Bar

Product Code: A971IPS-30

The Meech 971IPS-30 Extra Long-Range Pulsed DC Ionising Bar is the latest addition to the Meech Hyperion Range.

The 971IPS-30 is powered by an integrated +/- 30kV 24V DC power supply, making it the most powerful ionising bar in Meech’s range.

The 971IPS-30 is suitable for ultra-long range applications from 450 to 1500mm.

Equipped with Meech’s Ion Current Monitoring (ICM) technology, beam performance is maintained with local and remote alarms indicating when the beam needs cleaning. The Hyperion BarMaster remote programmer can also be used to adjust the frequency and balance of the bar, optimizing it for each application.

  Download
Features & Benefits
Optimum working distance

450-1500mm suitable for long reach applications such as slitter rewinders, transit bag machines and turret rewinders.

Low voltage wiring

Requiring a 24V DC power supply eliminates the need for high-voltage wiring to the ionisation strip.

Integrated power supply (IPS)

The integrated power supply delivers +/- 30kV pulsed DC.

Adjustable output

Frequency and balance can be adjusted with the optional BarMaster programmer.

Air Boost (air amplification)

Additional performance can be achieved through the use of integrated air support.

Adjustable Clean Pin Warning Signal

Meech Ion Current Monitoring (ICM) technology detects when the 971IPS-30 needs cleaning. An LED on the bar alerts operators when cleaning is required. This ensures peak performance is maintained.

Removable titanium emitters

Emitter pin assemblies are designed to be easy to clean and replace, allowing the 971IPS-30 to maintain performance for many years.

Remote signal

An output signal will be activated when the bar needs cleaning or a fault is detected. In this way, operators will be remotely notified when the bar needs to be serviced.

Technical Characteristics
Optimum Operating Distance

450 to 1200mm

Dimensions (WxH)

63mm x 70mm

Weight

1.2kg/metre

Construction

FR ABS

Mounting

Socket ‘T’ with M4 x 20mm pins

Emitters

Sharp titanium pins. Replaceable

Input Current

Max 625mA

Input Voltage

24VDC (21-27VDC)

Output voltage

2 to 15kVDC Pos/Neg

Output frequency

Default setting: 1Hz, Adjustable with BarMaster or SmartControl from 0.5H to 9.5Hz

Environmental protection

IP67

Output Balance

BarMaster ir SmartControl adjustable between 80:20 to 20:80 Pos:Neg (Defalt 60:40 Pos:Neg)

Baseline Balance

Default: 60% positive, 40% negative (adjustable with BarMaster)

Maximum Ambient Temperature

60°C

Air Boost Connection

6mm push-lift

Air Consumption

113 1/min per 1000mm at 1 bar

Maximum Length

3920mm

Electrical Connection

4-Pin, M8

Certificate

CE
