AHUv3 Mini – 1 Pump

Product Code: AHUv3 Mini

The AHUv3 Mini – 1 Pump provides the positive pressure and vacuum pressure airflows and houses the system filters. The AHUv3 Mini has been designed predominantly for narrow web applications, where a lower volume capacity is required. With a compact design, the AHUv3 Mini can be easily installed amongst existing machinery.

Download
Features & Benefits
Fully touch screen controlled

Allows a clear graphical display of the system settings and status whilst also making initial setup very fast.

Interlocks and signals

An interlock for remote start/stop of the AHUv3 ensures the system is always running during production. Signals for filter condition and to show the system is running are also provided.

Automatic vacuum pressure control

Removes the requirement of ongoing operator adjustment. A consistent level of cleaning is achieved for the full life of the filter, resulting in a consistent end product.

On-board ionisation

Power for the ionisation power supply is taken directly from the AHUv3, meaning only one main electrical supply is required for the system installation.

Technical Characteristics
Output

1.1kW

Capacity

366m³/hr

Weight

22kg

Noise Level

68dBa

Full Load Current @ 240V

Neutral = 7A, Line = 6A

Electrical Supply

110V/240V 1ph

Size

Height 520mm x Depth 300mm x Width 450mm

Full Load Current @ 110V

Neutral = 12A, Line = 12A

Exhauster

Turbine Fan

Filters

Bag – Efficiency F8 – 90-95% @ 0.4μ

Stainless Steel

Grade 430

Environmental Operating Range: Temperature

+5°C to +40°C

Environmental Operating Range: Humidity

Max 80% RH up to 31°C To Max 50% RH at 40°C

Environmental Operating Range: Altitude

Below 2000m

Environmental Operating Range: Pullution Degree

2
