AHUv3 Compact – 2 Pump

Product Code: AHUv3 Compact

The AHUv3 Compact provides the positive pressure and vacuum pressure airflows and houses the system filters. The AHUv3 Compact is a 2 pump unit designed predominantly for narrow web applications of up to 600mm.

Download
Features & Benefits
Touch screen

Clear visual representation of the system status: vacuum target pressures and vacuum and positive pressures

Digitally set Target Vacuum Pressure

Digital adjustments of 0.1kPa increments, for fast and accurate setup

Automatic Vacuum Pressure Control

System will clean effectively for the full life of the filters

Local / Remote Mode

Option of manual input or interlocked system

Control Lock

Option to password protect touch screen to ensure settings

Technical Characteristics
Output

2.2kW

Capacity

733 m³/hr

Weight

70kg

Noise Level

69dBa

Full Load Current @ 400V

Neutral = 11.3A, Line = 8.1A

Electrical Supply

200- 440V 3ph 50/60Hz

Size

Height 925mm x Depth 450mm x Width 450mm

Full Load Current @ 200V

Line = 17A

Exhauster

Turbine Fan

Filters

Bag – Efficiency F8 – 90-95% @ 0.4μ
HEPA – Efficiency H14 – 99.997% @ 0.3μ
Inline – Efficiency F8 – 90-95% @ 0.4μ

Stainless Steel

Grade 430

Environmental Operating Range: Temperature

+5°C to +40°C

Environmental Operating Range: Humidity

Max 80% RH up to 31°C To Max 50% RH at 40°C

Environmental Operating Range: Altitude

Below 2000m

Environmental Operating Range: Pullution Degree

2
