994 IML Static Generator

Product Code: 994 IML

The 994-IML Static Generator has been designed after consultation with “In Mould Labelling” OEM’s. The criteria they laid down was that the unit needed to be compact, light & reasonably priced.

The Meech 994-IML provides 0-20kV, Negative polarity, in a lightweight package with connections to suit the Meech Hydra IML pinning system.

  Download
Features & Benefits
0-20kV Output

Adjustable to suit all IML applications
Lightweight

Can be mounted on robot
24V DC Supply

Readily available on most machinery
Current Limiting Circuitry

Prevents damage to unit
Full Remote Control

Easy integration with PLC
Technical Characteristics
Dimensions

215 x 170 x 46 mm (W x H x D)
Weight

500g
Output Voltage

0 – 20kV Negative
Max Current

500 microAmps
Supply Voltage

24VDC
Front Panel

Flush rotary voltage controlPower LEDHT on LEDFault LED
Side Panel

24V DC inputPower ON/OFF Switch – latching push button3.5mm Jack Remote ON/OFF8 Pin Mini-DIN 2 x HT output sockets
Images
Documentation

Meech Static Control Brochure

Download

994IML Operating Manual

Download

A994IML

Download
Must Haves
Switchmode Power Adaptor 15W

Product Code: A900IPS-SM-15-XX

Meech Offer a suitable Switchmode Power Adaptor for the Hyperion 924IPS, 924IPSv2, 314IPS, 960IPS, 971IPS-30 and 650QAC Bars.

View Product
994 IML Static Generator

Product Code: 994 IML

The Meech 994-IML provides 0-20kV, Negative polarity, in a lightweight package with connections to suit the Meech Hydra IML pinning system.

View Product

994 IML Static Generator

Product Code: 994 IML

The 994-IML Static Generator has been designed after consultation with “In Mould Labelling” OEM’s. The criteria they laid down was that the unit needed to be compact, light & reasonably priced.

The Meech 994-IML provides 0-20kV, Negative polarity, in a lightweight package with connections to suit the Meech Hydra IML pinning system.



Features & Benefits
0-20kV Output Adjustable to suit all IML applications
Lightweight Can be mounted on robot
24V DC Supply Readily available on most machinery
Current Limiting Circuitry Prevents damage to unit
Full Remote Control Easy integration with PLC

Technical Characteristics
Dimensions 215 x 170 x 46 mm (W x H x D)
Weight 500g
Output Voltage 0 - 20kV Negative
Max Current 500 microAmps
Supply Voltage 24VDC
Front Panel Flush rotary voltage controlPower LEDHT on LEDFault LED
Side Panel 24V DC inputPower ON/OFF Switch - latching push button3.5mm Jack Remote ON/OFF8 Pin Mini-DIN 2 x HT output sockets

IonRinse™

Product Code: IonRinse™

The IonRinse system combines powerful DC ionisation, a custom designed airflow distributor and high quality inline filtration to provide the ultimate in ionised air rinsing.

The high velocity ionised air exits the IonRinse head unit via the airflow distributor. The control of the airflow coupled with the neutralisation of static charges releases contamination from the container which is extracted to the inline filter unit. The blow and vacuum airflows are provided by the central blow, vacuum and filtration unit.

Cleaning performance is maximised with the container fully inverted (opening facing down) as it travels over the IonRinse head.

In the videos tab, you’ll find an application video courtesy of Traktech SLL, which demonstrates how effective IonRinse is when removing flour from a container.

  Download
Features & Benefits
Improved Cleaning Quality

Low maintenance
No Water Costs

Low running cost
Fully Integrated Control System

Easy to maintain and use
Very Compact

Easy to install
Easy Integration into Existing Blower in Feed Formats

Easy to install
Minimal Maintenance Requirements

Easy to maintain
No Chemical Costs

Low running cost
No Compressed Air Costs

Low running cost
No Water/Chemical Residue

Easily kept clean
No Effluent Costs

Low running cost
Technical Characteristics
Stainless Steel Construction

High quality and suitable for use in washdown environments
Teflon Air Distributor

Customised to suit the container and line speed to ensure maximum performance. Teflon material allows the container to run in contact with the surface
Twin DC Ionising Bars

Built in redundancy with stand alone ‘primary’ and ‘reserve’ ionisation systems
Large Plenums

Help ensure even airflows along both the air distribution and vacuum slots
Constant Vacuum Along Length

Designed to catch the maximum level of removed contamination
Drop down access panel

Easy maintenance; the ionising bars drop out of the head unit mounted to the access panel
Selectable Handing

The air inlet and vacuum ducts can be connected at either end of the head unit to suit the installation space available
Single Phase 90-250V AC, 50/60Hz electrical supply

Ease of installation irrespective of available voltage to frequency
Variable Flow Control

Performance can be optimised to suit the process
HEPA and Bag Filtration

Excellent level of filtration; 6m2 of E13 media efficient to 99.99% at 0.3 micron and 6m2 F8 media efficient to 90 – 95% at 0.4 micron
Contacts for Auto Start/Stop

Can be linked to run with the line giving further energy savings
Wall or Floor Mounts

Can suit all installation areas
Houses Ionisation Power Supplies

Ease of installation
Contacts for Filter Condition Status

Filter status can be linked to line monitoring system
LED Displays for Ionisation Status

Allows ease of monitoring
Applications
Images
Videos
Documentation

IonRinse™ Head Dimensions

Download

IonRinse™ Blow, Vacuum and Filter Unit Dimensions

Download

Meech IonRinse™ Brochure - English

Download

IonRinse™ Performance Graphs

Download
Must Haves
AHUv3 Standard – 3 Pump or 6 Pump

Product Code: A-AHUV3-3PUMP/6PUMP

The AHUv3 provides the positive pressure and vacuum pressure airflows and houses the system filters. There are 2 models available, a 3 pump unit and a 6 pump unit. For applications where a higher volume capacity is required the 6 pump unit can be used.

View Product

IonRinse™

Product Code: IonRinse™

The IonRinse system combines powerful DC ionisation, a custom designed airflow distributor and high quality inline filtration to provide the ultimate in ionised air rinsing.

The high velocity ionised air exits the IonRinse head unit via the airflow distributor. The control of the airflow coupled with the neutralisation of static charges releases contamination from the container which is extracted to the inline filter unit. The blow and vacuum airflows are provided by the central blow, vacuum and filtration unit.

Cleaning performance is maximised with the container fully inverted (opening facing down) as it travels over the IonRinse head.

In the videos tab, you’ll find an application video courtesy of Traktech SLL, which demonstrates how effective IonRinse is when removing flour from a container.



Features & Benefits
Improved Cleaning Quality Low maintenance
No Water Costs Low running cost
Fully Integrated Control System Easy to maintain and use
Very Compact Easy to install
Easy Integration into Existing Blower in Feed Formats Easy to install
Minimal Maintenance Requirements Easy to maintain
No Chemical Costs Low running cost
No Compressed Air Costs Low running cost
No Water/Chemical Residue Easily kept clean
No Effluent Costs Low running cost

Technical Characteristics
Stainless Steel Construction High quality and suitable for use in washdown environments
Teflon Air Distributor Customised to suit the container and line speed to ensure maximum performance. Teflon material allows the container to run in contact with the surface
Twin DC Ionising Bars Built in redundancy with stand alone 'primary' and 'reserve' ionisation systems
Large Plenums Help ensure even airflows along both the air distribution and vacuum slots
Constant Vacuum Along Length Designed to catch the maximum level of removed contamination
Drop down access panel Easy maintenance; the ionising bars drop out of the head unit mounted to the access panel
Selectable Handing The air inlet and vacuum ducts can be connected at either end of the head unit to suit the installation space available
Single Phase 90-250V AC, 50/60Hz electrical supply Ease of installation irrespective of available voltage to frequency
Variable Flow Control Performance can be optimised to suit the process
HEPA and Bag Filtration Excellent level of filtration; 6m2 of E13 media efficient to 99.99% at 0.3 micron and 6m2 F8 media efficient to 90 - 95% at 0.4 micron
Contacts for Auto Start/Stop Can be linked to run with the line giving further energy savings
Wall or Floor Mounts Can suit all installation areas
Houses Ionisation Power Supplies Ease of installation
Contacts for Filter Condition Status Filter status can be linked to line monitoring system
LED Displays for Ionisation Status Allows ease of monitoring

976 Emitter Pin Set

Product Code: A976-PINSET

Meech offer a replacement 976 emitter pin set to allow the 976EX Long-Range Ionising Bar to be kept in as-new condition. The set is supplied as a bag of 5 x green and 5 x red replacement Titanium pin assemblies.

  Download
Must Haves
976EX Long-Range Ionising Bar 976EX Long-Range Ionising Bar

Product Code: A976EX-XXXX

View Product

976 Emitter Pin Set

Product Code: A976-PINSET

Meech offer a replacement 976 emitter pin set to allow the 976EX Long-Range Ionising Bar to be kept in as-new condition. The set is supplied as a bag of 5 x green and 5 x red replacement Titanium pin assemblies.



900-Air – Air Assist

Product Code: 900-AIR

The effective range of bars can be increased by the addition of an air-boost system.

The air assist option is suitable for model 915 and 910 bars.

  Download
Images
Must Haves
915 Anti-Static Bar

Product Code: A915-XXXX

Fast and powerful static control for high-speed applications with effective ionisation up to distances of 150mm.

View Product
914 Ionising Bar 914 Short-Range Ionising Bar

Product Code: A914-XXXX

View Product
Test Kit – 983v2 & 984v2

Product Code: 983V2-984V2-KIT

The 983v2 & 984v2 test kit allows diagnosis of static related issues and ionising equipment performance monitoring.

View Product

900-Air – Air Assist

Product Code: 900-AIR

The effective range of bars can be increased by the addition of an air-boost system.

The air assist option is suitable for model 915 and 910 bars.



915-Dust – Dust Proof Coating

Product Code: A915-DUST

For installation in dirty or dusty environments, the dust proof option improves resilience of the bar.

This option is suitable for the model 915 shockless bar.

  Download
Images
Related Products
915-WRES Water Resistant Coating

Product Code: 915-WRES

A water resistant option allows the installation of bars where routine machine cleaning can cause them to be splashed.

View Product
Test Kit – 983v2 & 984v2

Product Code: 983V2-984V2-KIT

The 983v2 & 984v2 test kit allows diagnosis of static related issues and ionising equipment performance monitoring.

View Product
Must Haves
915 Anti-Static Bar

Product Code: A915-XXXX

Fast and powerful static control for high-speed applications with effective ionisation up to distances of 150mm.

View Product

915-Dust – Dust Proof Coating

Product Code: A915-DUST

For installation in dirty or dusty environments, the dust proof option improves resilience of the bar.

This option is suitable for the model 915 shockless bar.



914 Short-Range Ionising Bar

Product Code: A914-XXXX

The powerful 914 Short-Range Ionising Bar is a highly effective static elimination solution, used across a wide range of industrial processes and industries worldwide. Specifically designed for neutralising static electricity where unwanted static charges can disrupt production, damage materials, or pose safety risks.

Featuring sharp titanium emitter pins, the 914 provides long-term performance. These pins are resistively coupled for shockless operation, making the device safe and therefore enhancing operator safety. Additionally, the 914 Short-Range Ionising Bar delivers effective ionisation up to distances of 100mm. Its design allows it to meet even the most demanding static control problems, including those encountered in high-speed applications. Furthermore, the 914 Ionising Bar holds CE and UL certifications. The model 914 operates with Meech’s 906 Power Unit pre-set to 5kV.

This market-leading static eliminator is suitable for most industrial processes. For solutions in hazardous zones, click here.

  Download
Features & Benefits
Shockless Emitters

Resistively coupled emitters for shockless operation and maximum safety.
Powerful Ion Production

Very fast decay times and effective at faster web speeds.
Sharp Titanium Emitters

Sharp Titanium emitters for long-term performance and reduced pin contamination.
Small Cross-Section

Suitable for installations where space is limited.
Operating Distance

25 – 100mm
Power Unit

Use with Meech 906 Power Unit.
Technical Characteristics
Construction

Anodised aluminium outer, PVC extruded liner, resin potted components and Titanium emitters.
Certification

CE & UL.
Dimensions

15mm x 18mm (W x H). Available lengths: from 80 to 4000mm.
Mounting

M4 x 20mm studs.
Weight

Approximately 400 grams per metre.
Operating Voltage

5.0kV AC.
Cable

HT cable in shielded flexible conduit. Standard length is 2m – longer lengths can be specified at time of order.
Options

Right angle cable entry via elbow option.
Power Unit

Use with Meech’s 906 Power Unit.
Variants

EX-ATEX version – see 914EX Short-Range Ionising Bar.
Images
914
Documentation

Meech Static Control Brochure

Download

914 Technical Drawing 40mm

Download

914 UL Certificate

Download
Related Products
914EX Short-Range Ionising Bar 914EX Short-Range Ionising Bar

Product Code: A914EX-XXXX

View Product
Must Haves
Power Unit 906 Power Unit

Product Code: A906

View Product

914 Short-Range Ionising Bar

Product Code: A914-XXXX

The powerful 914 Short-Range Ionising Bar is a highly effective static elimination solution, used across a wide range of industrial processes and industries worldwide. Specifically designed for neutralising static electricity where unwanted static charges can disrupt production, damage materials, or pose safety risks.

Featuring sharp titanium emitter pins, the 914 provides long-term performance. These pins are resistively coupled for shockless operation, making the device safe and therefore enhancing operator safety. Additionally, the 914 Short-Range Ionising Bar delivers effective ionisation up to distances of 100mm. Its design allows it to meet even the most demanding static control problems, including those encountered in high-speed applications. Furthermore, the 914 Ionising Bar holds CE and UL certifications. The model 914 operates with Meech’s 906 Power Unit pre-set to 5kV.

This market-leading static eliminator is suitable for most industrial processes. For solutions in hazardous zones, click here.



Features & Benefits
Shockless Emitters Resistively coupled emitters for shockless operation and maximum safety.
Powerful Ion Production Very fast decay times and effective at faster web speeds.
Sharp Titanium Emitters Sharp Titanium emitters for long-term performance and reduced pin contamination.
Small Cross-Section Suitable for installations where space is limited.
Operating Distance 25 - 100mm
Power Unit Use with Meech 906 Power Unit.

Technical Characteristics
Construction Anodised aluminium outer, PVC extruded liner, resin potted components and Titanium emitters.
Certification CE & UL.
Dimensions 15mm x 18mm (W x H). Available lengths: from 80 to 4000mm.
Mounting M4 x 20mm studs.
Weight Approximately 400 grams per metre.
Operating Voltage 5.0kV AC.
Cable HT cable in shielded flexible conduit. Standard length is 2m - longer lengths can be specified at time of order.
Options Right angle cable entry via elbow option.
Power Unit Use with Meech's 906 Power Unit.
Variants EX-ATEX version - see 914EX Short-Range Ionising Bar.

994 Hydra Static Pinner

Product Code: 994-HYDRA

The 994 Hydra Static Pinner is a static generation solution specifically designed for In-Mould Labelling (IML) applications where items with a small diameter are being moulded, for example yogurt pots or drinks containers, that require small pinning heads. Operating up to 20kV with power from a Meech 994 IML Static Generator, or 25kV with a Meech 994CG Compact Generator. As a result, the 994 Hydra Static Pinner ensures efficient label placement by securely pinning small objects to the surface using a static charge, improving process productivity and product quality in challenging moulding applications.

The 994 has a compact design for pinning of the smallest areas with accuracy and control. It is available in three sizes for varying intensities: 2-way, 4-way and 6-way, enabling multiple pinning points from a single static generator to accommodate various production requirements. Additionally, it offers flexibility through two cable configuration options: silicone pinner cables or TV20 pinner cables, depending on your application needs. Furthermore, the distributor is resistively coupled ensuring safe, shockless pinning and provides independent operation of the pinning heads.

994 Hydra Static Pinners are used in a wide range of industries such as printing, packaging and plastics.

Finally, for applications where space is even more limited, the 994 Hydra Static Pinner is also available in a miniature version. The 994 Hydra Compact Static Pinner provides the same efficient performance in an ultra-compact, space-saving form.

  Download
Features & Benefits
Compact Design

For pinning of the smallest areas.
Small Distributor Housing

Easily mounted on tools.
Resistively Coupled

Shockless, resistively coupled for safety.
Options

Three sizes for varying intensities: 2-way, 4-way and 6-way and two cable configurations for flexibility: silicone pinner cables or TV20 pinner cables.
Technical Characteristics
Construction

Pinning head: PTFE. Distributor: ABS. Splitter: PVC.
Generator

Use with Meech generators. State generator model at time of order.
Dimensions

Pinning head: Diameter 15mm. Distributor: 50mm x 86mm.
Cable

Supply Cable: 1m of cable. Pinning head: 0.45mm. Longer lengths can be specified at time of order.
Weight

175g.
Environmental

Temperature of Pinning head 105°C max. Distributor 90°C max. Splitter 65°C max.
Applications
Must Haves
994 IML Static Generator

Product Code: 994 IML

The Meech 994-IML provides 0-20kV, Negative polarity, in a lightweight package with connections to suit the Meech Hydra IML pinning system.

View Product
Hyperion 994CG – Compact Generator

Product Code: A994CG

The 994CG is designed for the IML market to meet the demand for a compact, lightweight generator to fit on the end of a robot arm.

View Product

994 Hydra Static Pinner

Product Code: 994-HYDRA

The 994 Hydra Static Pinner is a static generation solution specifically designed for In-Mould Labelling (IML) applications where items with a small diameter are being moulded, for example yogurt pots or drinks containers, that require small pinning heads. Operating up to 20kV with power from a Meech 994 IML Static Generator, or 25kV with a Meech 994CG Compact Generator. As a result, the 994 Hydra Static Pinner ensures efficient label placement by securely pinning small objects to the surface using a static charge, improving process productivity and product quality in challenging moulding applications.

The 994 has a compact design for pinning of the smallest areas with accuracy and control. It is available in three sizes for varying intensities: 2-way, 4-way and 6-way, enabling multiple pinning points from a single static generator to accommodate various production requirements. Additionally, it offers flexibility through two cable configuration options: silicone pinner cables or TV20 pinner cables, depending on your application needs. Furthermore, the distributor is resistively coupled ensuring safe, shockless pinning and provides independent operation of the pinning heads.

994 Hydra Static Pinners are used in a wide range of industries such as printing, packaging and plastics.

Finally, for applications where space is even more limited, the 994 Hydra Static Pinner is also available in a miniature version. The 994 Hydra Compact Static Pinner provides the same efficient performance in an ultra-compact, space-saving form.



Features & Benefits
Compact Design For pinning of the smallest areas.
Small Distributor Housing Easily mounted on tools.
Resistively Coupled Shockless, resistively coupled for safety.
Options Three sizes for varying intensities: 2-way, 4-way and 6-way and two cable configurations for flexibility: silicone pinner cables or TV20 pinner cables.

Technical Characteristics
Construction Pinning head: PTFE. Distributor: ABS. Splitter: PVC.
Generator Use with Meech generators. State generator model at time of order.
Dimensions Pinning head: Diameter 15mm. Distributor: 50mm x 86mm.
Cable Supply Cable: 1m of cable. Pinning head: 0.45mm. Longer lengths can be specified at time of order.
Weight 175g.
Environmental Temperature of Pinning head 105°C max. Distributor 90°C max. Splitter 65°C max.

VacClean™ Contact Web Cleaning System

Product Code: VacClean™

The Meech VacClean™ contact web cleaning system is an evolution of Meech’s successful Tornado system, of which there are hundreds of installations globally. VacClean systems incorporate an enhanced contact cleaning manifold with either an Air Handling Unit (AHU) or vacuum fan unit, depending on the installation environment and web width.

  Download
Features & Benefits
Twin AC Ionising Bars

Neutralise static charges on the web on entry and exit to the manifold
Highly Polished Stainless Steel Faceplates

Create turbulence to break the boundary layer
Brushes

Aid break up of the boundary layer without contacting the web surface
Technical Characteristics
Single or Double Sided

Both
Filtration

F8 media efficient to 90-95% at 0.4 micron, washable filter
Compact Web Contact Point

VacClean can be installed in areas with restricted space
Extraction Model

Air handling unit or vacuum fan unit
Applications
Related Products
TakClean™ Contact Web Cleaning System

Product Code: TakClean™

Meech TakClean™ contact web cleaning system is primarily used in the label and narrow web markets to remove dry, unbonded contamination from a moving web.

View Product
Must Haves
AHUv3 Mini – 1 Pump

Product Code: A-AHUV3-1PUMP

The AHUv3 Mini – 1 Pump provides the positive pressure and vacuum pressure airflows and houses the system filters.

View Product
AHUv3 Compact – 2 Pump

Product Code: A-AHUV3-2PUMP

The AHUv3 Compact provides the positive pressure and vacuum pressure airflows and houses the system filters. The AHUv3 Compact is a 2 pump unit designed predominantly for narrow web applications of up to 600mm.

View Product
AHUv3 Standard – 3 Pump or 6 Pump

Product Code: A-AHUV3-3PUMP/6PUMP

The AHUv3 provides the positive pressure and vacuum pressure airflows and houses the system filters. There are 2 models available, a 3 pump unit and a 6 pump unit. For applications where a higher volume capacity is required the 6 pump unit can be used.

View Product

VacClean™ Contact Web Cleaning System

Product Code: VacClean™

The Meech VacClean™ contact web cleaning system is an evolution of Meech’s successful Tornado system, of which there are hundreds of installations globally. VacClean systems incorporate an enhanced contact cleaning manifold with either an Air Handling Unit (AHU) or vacuum fan unit, depending on the installation environment and web width.



Features & Benefits
Twin AC Ionising Bars Neutralise static charges on the web on entry and exit to the manifold
Highly Polished Stainless Steel Faceplates Create turbulence to break the boundary layer
Brushes Aid break up of the boundary layer without contacting the web surface

Technical Characteristics
Single or Double Sided Both
Filtration F8 media efficient to 90-95% at 0.4 micron, washable filter
Compact Web Contact Point VacClean can be installed in areas with restricted space
Extraction Model Air handling unit or vacuum fan unit

995 Claw Style Edge Pinning

Product Code: A995-CLAW-1

The 995 Edge Pinning Claw is a powerful pinning head intended for use on cast-film lines. Pinning the edges of the cast film to the chill roller prevents necking of the film.  Resistively coupled titanium pins deliver spark free pinning.

The 995-CLAW can be powered from either our 30kV or 50kV range of IonCharge Static Generators.

  Download
Features & Benefits
Resistively Coupled

Spark free, independant operation
Flexible Titanium Pins

Adjustable to suit installation, long service life
Technical Characteristics
Operating Voltage

Up to 50kV D.C.
Operating Polarity

Either +VE or -VE
Max Temperature

Including conduit – 115°C
Head only – 130°C
Overall Dimensions

30 x 67 x 180mm
Pin Dimensions

2mm x 50mm
Cable Length

5000mm, longer upon request
Construction

PTFE body
Polyurethane potting compound
Titanium pins
Applications
Images
Documentation

Meech Static Control Brochure

Download

995 Claw Style Edge Pinning Technical Drawing

Download
Related Products
995 Pinning Head

Product Code: A995R-XXXX

The 995 range of Pinning Heads have been designed for use with all Meech static generators and can be operated at up to 50kV.

View Product
Must Haves
Hyperion IonCharge30 (15W)

Product Code: AIC30-15DC

The Meech IonCharge 30 uses advanced high voltage technology and software for a controlled static charge via our range of static generator bars and pinning heads.

View Product
Switchmode Power Adaptor 48W

Product Code: A900IPS-SM-48W-XX

A 24V DC 48W Power Adaptor for use with certain products within the Meech range.

View Product
Switchmode Power Adaptor 100W Switchmode Power Adaptor 100W

Product Code: A900IPS-SM-96W-XX

A general 24V DC 45W Power Adaptor.

View Product
Hyperion IonCharge50 (75W)

Product Code: AIC50-75DC

IonCharge50 – 75W static generator is designed for a range of applications. It uses advanced high voltage technology and software for a controlled static charge via our range of static generator bars and pinning heads.

View Product

995 Claw Style Edge Pinning

Product Code: A995-CLAW-1

The 995 Edge Pinning Claw is a powerful pinning head intended for use on cast-film lines. Pinning the edges of the cast film to the chill roller prevents necking of the film.  Resistively coupled titanium pins deliver spark free pinning.

The 995-CLAW can be powered from either our 30kV or 50kV range of IonCharge Static Generators.



Features & Benefits
Resistively Coupled Spark free, independant operation
Flexible Titanium Pins Adjustable to suit installation, long service life

Technical Characteristics
Operating Voltage Up to 50kV D.C.
Operating Polarity Either +VE or -VE
Max Temperature Including conduit - 115°C Head only - 130°C
Overall Dimensions 30 x 67 x 180mm
Pin Dimensions 2mm x 50mm
Cable Length 5000mm, longer upon request
Construction PTFE body Polyurethane potting compound Titanium pins

JetStream™ Non-Ionising Air Knife System

Product Code: AJS-O-XXXX-01

The unbeatable JetStream™ Non-Ionising Air Knife System delivers a product/surface drying and cooling solution across a diverse range of industries.

The blower produces a high volume of air which exits the air knife through a preset slot in the manifold and targets the surface with precision and minimal air turbulence. At this point, the high-pressure air effectively dries and cools the surface or product.

We developed the JetStream™ Non-Ionising Air Knife System for industries such as Food/Beverage, Metal, Packaging and Automotive, particularly for applications where static neutralisation is not necessary. We engineer the system using hard anodised aluminium and stainless steel, making it suitable for use in most environments.

Additionally, the JetStream™ Non-Ionising Air Knife System has several benefits over other air blow system styles. Particularly, it reduces running costs by typically 70-90% compared to compressed air alternatives and delivers a more balanced, consistent performance.

Evidently, JetStream™ Non-Ionising Air Knife System provides a better performing, energy efficient and low maintenance solution, leading to higher profitability and more manageable production yields.

  Download
Features & Benefits
Energy Efficient Fan Blown Air

Cost efficient compared to compressed air.
Air Entrainment Deflectors

Minimise the volume of potentially contaminated ambient air that is entrained by the Air Knife and blown onto the target substrate.
Optimised Cleaning Performance

Delivers a clean airflow, essential for optimum cleaning performance.
Large Plenum

Ensures even delivery of the airflow along the length of the Air Knife.
High Volume and Pressure of Air

Provides both high air pressure and high air volume, key factors in cleaning performance.
Continuous Blade of Air

Delivers a uniform, continuous blade of ionised air for consistent performance.
Easy Maintenance

Unique design characteristics greatly simplifies maintenance procedures.
Optional Air Feed Locations

Top and end feed Air Knives are available for applications where installation height is restricted (end feed is only available for Air Knives up to 1000mm).
Material

Constructed from hard anodised aluminium and stainless steel, making
it suitable for use in most environments.
Technical Characteristics
Available Lengths

From 200mm to 3000mm. If a longer Air Knife is required, please contact us.
Optional Silencing/Acoustic Enclosure

Inlet/outlet blower silencer and acoustic enclosure options to control noise levels to as low as 70dBA.
Construction

Hard-anodised aluminium main body and stainless steel end plates and fixings, making it suitable for most environments.
Optional Control System

Three different types of control systems available. No control, simple control or PLC. The simple control is supplied with on/off/E-stop buttons to control the unit manually. PLC can be integrated with the line to control the blower, ionisation and profiling.
Optional Filtration

Inlet or inline filtration options, as standard rated to 5 micron.
Applications
Documentation
Related Products

JetStream™ Non-Ionising Air Knife System

Product Code: AJS-O-XXXX-01

The unbeatable JetStream™ Non-Ionising Air Knife System delivers a product/surface drying and cooling solution across a diverse range of industries.

The blower produces a high volume of air which exits the air knife through a preset slot in the manifold and targets the surface with precision and minimal air turbulence. At this point, the high-pressure air effectively dries and cools the surface or product.

We developed the JetStream™ Non-Ionising Air Knife System for industries such as Food/Beverage, Metal, Packaging and Automotive, particularly for applications where static neutralisation is not necessary. We engineer the system using hard anodised aluminium and stainless steel, making it suitable for use in most environments.

Additionally, the JetStream™ Non-Ionising Air Knife System has several benefits over other air blow system styles. Particularly, it reduces running costs by typically 70-90% compared to compressed air alternatives and delivers a more balanced, consistent performance.

Evidently, JetStream™ Non-Ionising Air Knife System provides a better performing, energy efficient and low maintenance solution, leading to higher profitability and more manageable production yields.



Features & Benefits
Energy Efficient Fan Blown Air Cost efficient compared to compressed air.
Air Entrainment Deflectors Minimise the volume of potentially contaminated ambient air that is entrained by the Air Knife and blown onto the target substrate.
Optimised Cleaning Performance Delivers a clean airflow, essential for optimum cleaning performance.
Large Plenum Ensures even delivery of the airflow along the length of the Air Knife.
High Volume and Pressure of Air Provides both high air pressure and high air volume, key factors in cleaning performance.
Continuous Blade of Air Delivers a uniform, continuous blade of ionised air for consistent performance.
Easy Maintenance Unique design characteristics greatly simplifies maintenance procedures.
Optional Air Feed Locations Top and end feed Air Knives are available for applications where installation height is restricted (end feed is only available for Air Knives up to 1000mm).
Material Constructed from hard anodised aluminium and stainless steel, making it suitable for use in most environments.

Technical Characteristics
Available Lengths From 200mm to 3000mm. If a longer Air Knife is required, please contact us.
Optional Silencing/Acoustic Enclosure Inlet/outlet blower silencer and acoustic enclosure options to control noise levels to as low as 70dBA.
Construction Hard-anodised aluminium main body and stainless steel end plates and fixings, making it suitable for most environments.
Optional Control System Three different types of control systems available. No control, simple control or PLC. The simple control is supplied with on/off/E-stop buttons to control the unit manually. PLC can be integrated with the line to control the blower, ionisation and profiling.
Optional Filtration Inlet or inline filtration options, as standard rated to 5 micron.

JetStream™ Ionising Air Knife System

Product Code: AJS-I-XXXX-01

The unbeatable JetStream™ Ionising Air Knife System removes contamination and eliminates static from a diverse range of applications.

The blower produces a high volume of air which exits the air knife through a preset slot in the manifold and targets the surface with precision and minimal air turbulence. At this point, powerful ionisation neutralises the static charge that holds the dust in place, allowing the ionised air to effectively dislodge and remove the contamination.

The JetStream™ Ionising Air Knife System features twin AC 914 Short-Range Ionising Bars and requires a 906 Power Unit. We developed this system for industries such as Food/Beverage, Plastics, Glass, Metal, Packaging & Automotive and engineer it using hard anodised aluminium and stainless steel, making it suitable for use in most environments.

Additionally, the JetStream™ Ionising Air Knife System has several benefits over other air blow system styles. Particularly, it reduces running costs by typically 70-90% compared to compressed air alternatives and delivers a more balanced, consistent performance.

Evidently, JetStream™ Ionising Air Knife System provides a better performing, energy efficient and low maintenance solution, leading to higher profitability and more manageable production yields. For solutions in hazardous zones, click here.

  Download
Features & Benefits
Integral Twin Ionising Bars

Incorporates Meech 914 Short-Range Ionising Bars that deliver a balanced, continuous blade of ionised air for totally consistent performance to quickly neutralise static, facilitating easy removal of contamination.
Material

Constructed from hard anodised aluminium and stainless steel, making
it suitable for use in most environments.
Energy Efficient Fan Blown Air

Cost efficient compared to compressed air.
Air Entrainment Deflectors

Minimises the volume of potentially contaminated ambient air that is entrained by the Air Knife and blown onto the target substrate.
Optimised Cleaning Performance

Delivers a clean ionised airflow, essential for optimum cleaning performance.
Large Plenum

Ensures even delivery of the airflow along the length of the Air Knife.
High Volume and Pressure of Air

Provides both high air pressure and high air volume, key factors in cleaning performance.
Optional Air Feed Locations

Top and end feed Air Knives are available for applications where installation height is restricted (end feed is only available for Air Knives up to 1000mm).
Continuous Blade of Ionised Air

Delivers a uniform, continuous blade of ionised air for consistent performance.
Optional Silencing/Acoustic Enclosure

Inlet/outlet blower silencer and acoustic enclosure options to control noise levels to as low as 70dBA.
Easy Maintenance

Unique design characteristics greatly simplifies maintenance procedures.
Technical Characteristics
Construction

Hard-anodised aluminium main body, stainless steel end plates and fixings. Titanium emitters.
Optional Filtration

Inlet or inline filtration options, as standard rated to 5 micron.
Ionising Bar Construction

Anodised aluminium outer with PVC extruded liner and resin potted components.
Optional Silencing/Acoustic Enclosure

Inlet/outlet blower silencer and acoustic enclosure options to control noise levels to as low as 70dBA.
Available Lengths

From 300mm to 3000mm. If a longer Air Knife is required, please contact us.
Optional Control System

Three different types of control systems available. No control, simple control or PLC. The simple control is supplied with on/off/E-stop buttons to control the unit manually. PLC can be integrated with the line to control the blower, ionisation and profiling.
Power Unit

Use with a Meech Power Unit to power the ionising bars.
Applications
Images
JetStream™ Ionising Air Knife
JetStream™ Ionising Air Knife
JetStream™ Ionising Air Knife
JetStream™ Ionising Air Knife
JetStream™ Ionising Air Knife
Documentation

JetStream Brochure 2018

Download
Related Products
Must Haves
Power Unit 906 Power Unit

Product Code: A906

View Product

JetStream™ Ionising Air Knife System

Product Code: AJS-I-XXXX-01

The unbeatable JetStream™ Ionising Air Knife System removes contamination and eliminates static from a diverse range of applications.

The blower produces a high volume of air which exits the air knife through a preset slot in the manifold and targets the surface with precision and minimal air turbulence. At this point, powerful ionisation neutralises the static charge that holds the dust in place, allowing the ionised air to effectively dislodge and remove the contamination.

The JetStream™ Ionising Air Knife System features twin AC 914 Short-Range Ionising Bars and requires a 906 Power Unit. We developed this system for industries such as Food/Beverage, Plastics, Glass, Metal, Packaging & Automotive and engineer it using hard anodised aluminium and stainless steel, making it suitable for use in most environments.

Additionally, the JetStream™ Ionising Air Knife System has several benefits over other air blow system styles. Particularly, it reduces running costs by typically 70-90% compared to compressed air alternatives and delivers a more balanced, consistent performance.

Evidently, JetStream™ Ionising Air Knife System provides a better performing, energy efficient and low maintenance solution, leading to higher profitability and more manageable production yields. For solutions in hazardous zones, click here.



Features & Benefits
Integral Twin Ionising Bars Incorporates Meech 914 Short-Range Ionising Bars that deliver a balanced, continuous blade of ionised air for totally consistent performance to quickly neutralise static, facilitating easy removal of contamination.
Material Constructed from hard anodised aluminium and stainless steel, making it suitable for use in most environments.
Energy Efficient Fan Blown Air Cost efficient compared to compressed air.
Air Entrainment Deflectors Minimises the volume of potentially contaminated ambient air that is entrained by the Air Knife and blown onto the target substrate.
Optimised Cleaning Performance Delivers a clean ionised airflow, essential for optimum cleaning performance.
Large Plenum Ensures even delivery of the airflow along the length of the Air Knife.
High Volume and Pressure of Air Provides both high air pressure and high air volume, key factors in cleaning performance.
Optional Air Feed Locations Top and end feed Air Knives are available for applications where installation height is restricted (end feed is only available for Air Knives up to 1000mm).
Continuous Blade of Ionised Air Delivers a uniform, continuous blade of ionised air for consistent performance.
Optional Silencing/Acoustic Enclosure Inlet/outlet blower silencer and acoustic enclosure options to control noise levels to as low as 70dBA.
Easy Maintenance Unique design characteristics greatly simplifies maintenance procedures.

Technical Characteristics
Construction Hard-anodised aluminium main body, stainless steel end plates and fixings. Titanium emitters.
Optional Filtration Inlet or inline filtration options, as standard rated to 5 micron.
Ionising Bar Construction Anodised aluminium outer with PVC extruded liner and resin potted components.
Optional Silencing/Acoustic Enclosure Inlet/outlet blower silencer and acoustic enclosure options to control noise levels to as low as 70dBA.
Available Lengths From 300mm to 3000mm. If a longer Air Knife is required, please contact us.
Optional Control System Three different types of control systems available. No control, simple control or PLC. The simple control is supplied with on/off/E-stop buttons to control the unit manually. PLC can be integrated with the line to control the blower, ionisation and profiling.
Power Unit Use with a Meech Power Unit to power the ionising bars.

Test Kit – 983v2 & 984v2

Product Code: 983V2-984V2-KIT

The Meech 983v2 & 984v2 test kit gives operators & maintenance staff the ability to diagnose static related issues and monitor the performance of their ionising equipment.

The model 983v2 Static Locator features a large LCD display for clear reading of static voltages. The model 984v2 is a true ion detector for both AC and pulsed DC ionisers. LED’s show the presence, or not, of ions. Decreased detection range indicates the need to clean ionisers.

Please see individual data sheets for 983v2 and 984v2 for more detailed information.

Please view the video below for more information on the model 983v2 Static Locator:

Please view the video below for more information on the model 984v2 Ion Sensor:

  Download
Features & Benefits
All In One Test Kit

Full test kit, as used by Meech engineers. In one carry case.
Technical Characteristics
Weight

715g
Battery

Both operate from 2 x AA alkaline batteries
Dimension (mm)

235 x 200 x 55
Images
Related Products
983v2 Static Locator

Product Code: 983v2

The Model 983v2 Static Locator provides accurate measurement of electrostatic charges. Its design enables fast response, low drift and ease of operation.

View Product
984v2 Ion Sensor

Product Code: A984V2

The Meech Model 984v2 Ion Sensor is an easy-to-use device for checking the performance of both AC and DC powered static eliminator bars.

View Product
Must Haves
945IPS Ionising Bar 945IPS Mid-Range Ionising Bar

Product Code: A945IPS-XXXX





View Product
Hyperion 971IPS-30 Extra Long-Range Pulsed DC Ionising Bar

Product Code: A971IPS-30

The 971IPS-30 is powered by an integrated power supply (IPS) +/- 30kV 24V DC and is the most powerful ionisation strip in the Meech portfolio.

View Product
314 Hyperion 314IPS Hygienic Ionising Bar

Product Code: 314IPS

The Hyperion 314IPS hygienic bar is a compact ionising bar for short-range applications where hygiene and sterility is a critical factor.

View Product

Test Kit – 983v2 & 984v2

Product Code: 983V2-984V2-KIT

The Meech 983v2 & 984v2 test kit gives operators & maintenance staff the ability to diagnose static related issues and monitor the performance of their ionising equipment.

The model 983v2 Static Locator features a large LCD display for clear reading of static voltages. The model 984v2 is a true ion detector for both AC and pulsed DC ionisers. LED’s show the presence, or not, of ions. Decreased detection range indicates the need to clean ionisers.

Please see individual data sheets for 983v2 and 984v2 for more detailed information.

Please view the video below for more information on the model 983v2 Static Locator:

Please view the video below for more information on the model 984v2 Ion Sensor:



Features & Benefits
All In One Test Kit Full test kit, as used by Meech engineers. In one carry case.

Technical Characteristics
Weight 715g
Battery Both operate from 2 x AA alkaline batteries
Dimension (mm) 235 x 200 x 55

Needle Cooler

Product Code: A20503/A20504

The Meech Needle Cooler provides perfect spot cooling for any small application. Specifically aimed at cooling sewing needles, the Needle Cooler avoids needle breakages and thread burn. The cooler delivers a continuous adjustable stream of cold air onto any sewing machine needle. A magnetic mounting bracket means the cooler can be fixed to virtually any metal surface giving the versatility to aim cooling exactly at the spot needed. It is powered solely by compressed air and can reduce temperatures by as much as 34°C below air inlet temperature.

  Download
Features & Benefits
No Moving Parts

Low maintenance and easy to use
Stainless Steel

Suitable for harsh environments
Knuckle Trunking

Easy direction of cold airflow
Magnetic Base

Quick and easy mounting
Technical Characteristics
Dimensions (mm)

(L) 148mm x  (H) 45mm
Images
Documentation

Meech Air Technology - Vortex Cooling Range Brochure

Download

Needle_Cooler

Download

Needle Cooler

Product Code: A20503/A20504

The Meech Needle Cooler provides perfect spot cooling for any small application. Specifically aimed at cooling sewing needles, the Needle Cooler avoids needle breakages and thread burn. The cooler delivers a continuous adjustable stream of cold air onto any sewing machine needle. A magnetic mounting bracket means the cooler can be fixed to virtually any metal surface giving the versatility to aim cooling exactly at the spot needed. It is powered solely by compressed air and can reduce temperatures by as much as 34°C below air inlet temperature.



Features & Benefits
No Moving Parts Low maintenance and easy to use
Stainless Steel Suitable for harsh environments
Knuckle Trunking Easy direction of cold airflow
Magnetic Base Quick and easy mounting

Technical Characteristics
Dimensions (mm) (L) 148mm x  (H) 45mm

984v2 Ion Sensor

Product Code: A984V2

The Meech Model 984v2 Ion Sensor is an easy-to-use device for checking the performance of both AC and DC powered static eliminator bars.

Indicator lights confirm the presence of ions and, in the case of a DC power source, their polarity. Regular monitoring of installations with the model 984v2 will indicate when bars require cleaning or other maintenance work, thereby ensuring that bar performance and process efficiency can remain at the optimum level.

  Download
Features & Benefits
Simple to Operate

Provides reproducible results
Detects Ions

Unlike other devices that measure only electrical field strength, the 984v2
provides a direct indication of ionization
performance
Operates with Both AC and DC Power Sources

Can be used with a range of different types of installed equipment and with equipment from different manufacturers.
Measures Bar Performance in”situ”

Avoids the need to remove the bar for testing.
No User Serviceable Parts

No maintenance – only periodic battery replacement is required.
Technical Characteristics
Weight

168 grams (including battery)
Dimensions

142mm x 81mm x 25mm (h x w x d)
Battery

2 x AA alkaline
Indicator LED's

Power – Red, No Ions Detected – Red Flashing, AC Ions Detected – Yellow, Positive Ions Detected – Red, Negative Ions Detected – Green
Images
Documentation

Meech Static Control Brochure

Download

A984v2

Download
Related Products
Test Kit – 983v2 & 984v2

Product Code: 983V2-984V2-KIT

The 983v2 & 984v2 test kit allows diagnosis of static related issues and ionising equipment performance monitoring.

View Product
Programmer BarMaster Programmer

Product Code: A900-BARMASTER-F

View Product
Must Haves
945IPS Ionising Bar 945IPS Mid-Range Ionising Bar

Product Code: A945IPS-XXXX





View Product
Hyperion 971IPS-30 Extra Long-Range Pulsed DC Ionising Bar

Product Code: A971IPS-30

The 971IPS-30 is powered by an integrated power supply (IPS) +/- 30kV 24V DC and is the most powerful ionisation strip in the Meech portfolio.

View Product
314 Hyperion 314IPS Hygienic Ionising Bar

Product Code: 314IPS

The Hyperion 314IPS hygienic bar is a compact ionising bar for short-range applications where hygiene and sterility is a critical factor.

View Product

984v2 Ion Sensor

Product Code: A984V2

The Meech Model 984v2 Ion Sensor is an easy-to-use device for checking the performance of both AC and DC powered static eliminator bars.

Indicator lights confirm the presence of ions and, in the case of a DC power source, their polarity. Regular monitoring of installations with the model 984v2 will indicate when bars require cleaning or other maintenance work, thereby ensuring that bar performance and process efficiency can remain at the optimum level.



Features & Benefits
Simple to Operate Provides reproducible results
Detects Ions Unlike other devices that measure only electrical field strength, the 984v2 provides a direct indication of ionization performance
Operates with Both AC and DC Power Sources Can be used with a range of different types of installed equipment and with equipment from different manufacturers.
Measures Bar Performance in”situ” Avoids the need to remove the bar for testing.
No User Serviceable Parts No maintenance – only periodic battery replacement is required.

Technical Characteristics
Weight 168 grams (including battery)
Dimensions 142mm x 81mm x 25mm (h x w x d)
Battery 2 x AA alkaline
Indicator LED's Power - Red, No Ions Detected - Red Flashing, AC Ions Detected - Yellow, Positive Ions Detected - Red, Negative Ions Detected - Green

983v2 Static Locator

Product Code: 983v2

The Model 983v2 Static Locator provides accurate measurement of electrostatic charges. Its design enables fast response, low drift and ease of operation.

The 983v2 can operate in “Continuous” or “Peak Hold” mode to record changes in the level of charge or the highest charge detected respectively. It is suitable for use by production, maintenance, inspection and quality engineers and on any material where static charge may be an issue.

  Download
Features & Benefits
Compact design

Lightweight, pocket sized device
Large high contrast LCD screen with digital display

Easy to read in different lighting conditions
Continuous and Peak Hold modes

Can measure fluctuation in charge levels and/or the highest level detected
In-built distance meter

Clear indication of correct operating range for consistent, accurate readings
Robust plastic housing

High durability
Instrument case

Safe, clean storage when not in use
Technical Characteristics
Dimensions

143mm x 81mm x 25mm (H x W x D)
Weight

200g
Construction

Moulded plastic case, integral battery compartment, external earth connection
Measurement range

-200kV to 200kV at a distance of 150mm
Accuracy

+/-5%
Battery

2 x AA alkaline
Battery life

Approximately 10 hours of continuous use
Images
Documentation

Meech Static Control Brochure

Download

983v2 Operating Manual

Download

A983v2

Download
Related Products
Test Kit – 983v2 & 984v2

Product Code: 983V2-984V2-KIT

The 983v2 & 984v2 test kit allows diagnosis of static related issues and ionising equipment performance monitoring.

View Product
Programmer BarMaster Programmer

Product Code: A900-BARMASTER-F

View Product
Must Haves
945IPS Ionising Bar 945IPS Mid-Range Ionising Bar

Product Code: A945IPS-XXXX





View Product
Hyperion 971IPS-30 Extra Long-Range Pulsed DC Ionising Bar

Product Code: A971IPS-30

The 971IPS-30 is powered by an integrated power supply (IPS) +/- 30kV 24V DC and is the most powerful ionisation strip in the Meech portfolio.

View Product
314 Hyperion 314IPS Hygienic Ionising Bar

Product Code: 314IPS

The Hyperion 314IPS hygienic bar is a compact ionising bar for short-range applications where hygiene and sterility is a critical factor.

View Product

983v2 Static Locator

Product Code: 983v2

The Model 983v2 Static Locator provides accurate measurement of electrostatic charges. Its design enables fast response, low drift and ease of operation.

The 983v2 can operate in “Continuous” or “Peak Hold” mode to record changes in the level of charge or the highest charge detected respectively. It is suitable for use by production, maintenance, inspection and quality engineers and on any material where static charge may be an issue.



Features & Benefits
Compact design Lightweight, pocket sized device
Large high contrast LCD screen with digital display Easy to read in different lighting conditions
Continuous and Peak Hold modes Can measure fluctuation in charge levels and/or the highest level detected
In-built distance meter Clear indication of correct operating range for consistent, accurate readings
Robust plastic housing High durability
Instrument case Safe, clean storage when not in use

Technical Characteristics
Dimensions 143mm x 81mm x 25mm (H x W x D)
Weight 200g
Construction Moulded plastic case, integral battery compartment, external earth connection
Measurement range -200kV to 200kV at a distance of 150mm
Accuracy +/-5%
Battery 2 x AA alkaline
Battery life Approximately 10 hours of continuous use

Energy Saving Air Curtain

Product Code: A85000

Meech Air Curtains provide an efficient laminar sheet of compressed air for wide area blow-off and air drying applications.

The Air Curtain releases a small volume of compressed air through a 0.002″ (.0508mm) slot along its entire length. The ‘sheet’ of compressed air travels down the face of the Air Curtain creating an area of low pressure behind it that entrains ambient air at a ratio of up to 25:1 delivering a massive airflow to the target.

When used to replace drilled or slotted lengths of pipe, which consume vast volumes of compressed air, the Air Curtain offers compressed air savings of up to 70%.

  Download
Features & Benefits
Innovative Design

Giving 25:1 air amplification and meeting all Health and Safety requirements
No Moving Parts

Virtually no maintenance
Adjustability

Application specific set-up. Leading to hundreds of applications
Flange

Easy mounting
Lower Noise Levels

Dramatic reduction of noise compared to ‘open pipes’ up to 50dBA noise reduction.
Lower Compressed Air Usage

Lower running cost and in turn lower energy bills
Energy Saving

Can dramatically reduce compressed air usage
Technical Characteristics
Dimensions (mm)

(Length) Dependent on model x (Depth) 28mm x (Height) 42mm
Applications
Images
Videos
Documentation

Meech Air Technology - Air Efficiency Range Brochure

Download

Energy Saving Air Curtain Operating Manual

Download

Energy Saving Air Curtain

Product Code: A85000

Meech Air Curtains provide an efficient laminar sheet of compressed air for wide area blow-off and air drying applications.

The Air Curtain releases a small volume of compressed air through a 0.002″ (.0508mm) slot along its entire length. The ‘sheet’ of compressed air travels down the face of the Air Curtain creating an area of low pressure behind it that entrains ambient air at a ratio of up to 25:1 delivering a massive airflow to the target.

When used to replace drilled or slotted lengths of pipe, which consume vast volumes of compressed air, the Air Curtain offers compressed air savings of up to 70%.



Features & Benefits
Innovative Design Giving 25:1 air amplification and meeting all Health and Safety requirements
No Moving Parts Virtually no maintenance
Adjustability Application specific set-up. Leading to hundreds of applications
Flange Easy mounting
Lower Noise Levels Dramatic reduction of noise compared to 'open pipes' up to 50dBA noise reduction.
Lower Compressed Air Usage Lower running cost and in turn lower energy bills
Energy Saving Can dramatically reduce compressed air usage

Technical Characteristics
Dimensions (mm) (Length) Dependent on model x (Depth) 28mm x (Height) 42mm

995 Pinning Head

Product Code: A995R-XXXX

The 995 range of Pinning Heads have been designed for use with all Meech static generators*. All can be operated at up to 50kV and being resistively coupled, are near shockless in normal operation.

*Three sizes cover lengths 65mm, 107mm and 144mm

  Download
Features & Benefits
Resistively Coupled

Spark free, independant operation
High Pin Density

Powerful pinning
Technical Characteristics
Dimensions

4P2R  (L) 65mm x (W) 30mm x (H) 50mm
8P2R  (L) 107mm x (W) 30mm x (H) 50mm
12P2R  (L) 144mm x (W) 25mm x (H) 50mm
Operating Voltage

Up to 50kV D.C.
Cable

2 metres of EHT cable in flexible plastic conduit as standard, longer lengths can be specified when ordering
Construction

PTFE extrusion, titanium emitter pins
Max Temperature

115°C
Power Source

Meech Model 992v3
Operating Polarity

Either +VE or -VE
Applications
Images
Related Products
995 Claw Style Edge Pinning

Product Code: A995-CLAW-1

The 995 Edge Pinning Claw is a powerful pinning head intended for use on cast-film lines

View Product
Must Haves
Hyperion IonCharge30 (15W)

Product Code: AIC30-15DC

The Meech IonCharge 30 uses advanced high voltage technology and software for a controlled static charge via our range of static generator bars and pinning heads.

View Product
Hyperion IonCharge50 (75W)

Product Code: AIC50-75DC

IonCharge50 – 75W static generator is designed for a range of applications. It uses advanced high voltage technology and software for a controlled static charge via our range of static generator bars and pinning heads.

View Product
Switchmode Power Adaptor 15W

Product Code: A900IPS-SM-15-XX

Meech Offer a suitable Switchmode Power Adaptor for the Hyperion 924IPS, 924IPSv2, 314IPS, 960IPS, 971IPS-30 and 650QAC Bars.

View Product
Switchmode Power Adaptor 100W Switchmode Power Adaptor 100W

Product Code: A900IPS-SM-96W-XX

A general 24V DC 45W Power Adaptor.

View Product

995 Pinning Head

Product Code: A995R-XXXX

The 995 range of Pinning Heads have been designed for use with all Meech static generators*. All can be operated at up to 50kV and being resistively coupled, are near shockless in normal operation.

*Three sizes cover lengths 65mm, 107mm and 144mm



Features & Benefits
Resistively Coupled Spark free, independant operation
High Pin Density Powerful pinning

Technical Characteristics
Dimensions 4P2R  (L) 65mm x (W) 30mm x (H) 50mm 8P2R  (L) 107mm x (W) 30mm x (H) 50mm 12P2R  (L) 144mm x (W) 25mm x (H) 50mm
Operating Voltage Up to 50kV D.C.
Cable 2 metres of EHT cable in flexible plastic conduit as standard, longer lengths can be specified when ordering
Construction PTFE extrusion, titanium emitter pins
Max Temperature 115°C
Power Source Meech Model 992v3
Operating Polarity Either +VE or -VE

Cabinet Cooler

Product Code: A70000

The Meech Cabinet Cooler uses compressed air to provide a cold air source that stops industrial cabinets/panels or enclosures from overheating.

This IP66 rated model is both dust and watertight. Meaning water projected in powerful jets against the enclosure, from any direction, shall have no harmful effects.

The Cabinet Cooler has no electrical/electronic components making them entirely non-electrical. The cooling is provided from a Vortex Tube located inside the cooler. The Cabinet Cooler creates both a hot and cold stream of air, the cold air is directed inside the enclosure whilst the hot air is released to the atmosphere via two holes located on the side of the Cabinet Cooler.

The device is supplied with 4 x Generators that are used to regulate both the air consumption and air temperature. The Yellow 10CFM, Red 15CFM, Blue 25CFM and Brown 35CFM Generators can be easily switched to suit different conditions or applications.

The Cooler can be mounted to the directly to the top, side or underneath of the enclosure via a 26mm diameter hole. An O-ring seal between the Cabinet Cooler and the enclosure wall maintains the integrity of the enclosure.

The Cabinet Cooler is available in both Stainless Steel grades 303 and 316L, allowing it to be used in a wide variety of applications. A Cabinet Cooler System is also available, this includes a digital thermostat and Solenoid valve and allows the cooler to automatically maintain a set temperature. This reduces compressed air and running costs.

Product Codes

Cabinet Cooler unit – IP66 Cabinet Cooler in SS303 – A70025-SS303

Cabinet Cooler System – A70025-SS303 with 24V Thermostat and Solenoid – A70325-SS303-24V

Cabinet Cooler System – A70025-SS303 with 240V Thermostat and Solenoid – A70325-SS303-240V

Cabinet Cooler System – A70025-SS303 with 110V Thermostat and Solenoid – A70325-SS303-110V

Cabinet Cooler unit – IP66 Cabinet Cooler in SS316L – A70025-SS316

Cabinet Cooler System – A70025-SS316L with 24V Thermostat and Solenoid – A70325-SS316-24V

Cabinet Cooler System – A70025-SS316L with 240V Thermostat and Solenoid – A70325-SS316-240V

Cabinet Cooler System – A70025-SS316L with 110V Thermostat and Solenoid – A70325-SS316-110V

  Download
Features & Benefits
Innovative Design

Small Size allows installation into Small spaces
No Moving parts

Reduced maintenance
Adjustable

Supplied with 4 x Generators to control air volume and temperature.
Low noise

73dBA with red generator at 80 psi (5.4 Bar)
Cabinet Cooler System Available

Cabinet Cooler system includes a Digital Thermostat and Solenoid. These will allow you to control compressed air usage and reduce running costs.
Prevents dust and ingress

The Cabinet Cooler creates positive pressure inside cabinet to stop ingress
Cold Fraction

70% (2.5 Turns from closed)
EX version available

For use in Hazardous locations
Can be easily fitted to an existing panel/cabinet

Ideal replacement for fans that are more commonly used to cool cabinets
Technical Characteristics
Dimensions (mm)

(H) 194mm x (W) 45mm
Noise Level

73dBA (@ 80, psi, 5.5 Bar), with a Red Generator fitted.
Cooling Capacity

190 Watt (560 Btu/hr) to 703 Watt (2,400 Bty/hr)
IP Rating

IP66 (Test Certificate Number TRA055426CC01)
Maximum Inlet Air Pressure

80 psi (5.5 Bar)
Maximum Inlet Air Temperature

55°C
Metal Grade

Available in either Stainless Steel grade 303 or 316L
Pressure Relif Valve

Dependant on inlet pressure the cooler will vent air at between 1.5 & 3kPa (0.015 and 0.03 bar)
Thermal Endurance to heat test

In accordance with IEC6079-0:2017. Specimen subjected to three climatic pre-conditioning tests
Images
Videos
Documentation

Meech Air Technology - Vortex Cooling Range Brochure

Download

Cabinet Cooler Operating Manual

Download

A70025___Cabinet_Cooler

Download

Cabinet Cooler IP test certificate 2023

Download
Frequently Asked Questions
What is a Cabinet Cooler?
What size pipe for my compressed air system am I going to need when installing the Cabinet Cooler?
Related Products
EX Cabinet Cooler

Product Code: A70025EX-SS303 and A70025EX-SS316

The Meech EX Cabinet Cooler uses compressed air to provide a cold air source that stops industrial cabinets/panels or enclosures in hazardous locations from overheating.

View Product

Cabinet Cooler

Product Code: A70000

The Meech Cabinet Cooler uses compressed air to provide a cold air source that stops industrial cabinets/panels or enclosures from overheating.

This IP66 rated model is both dust and watertight. Meaning water projected in powerful jets against the enclosure, from any direction, shall have no harmful effects.

The Cabinet Cooler has no electrical/electronic components making them entirely non-electrical. The cooling is provided from a Vortex Tube located inside the cooler. The Cabinet Cooler creates both a hot and cold stream of air, the cold air is directed inside the enclosure whilst the hot air is released to the atmosphere via two holes located on the side of the Cabinet Cooler.

The device is supplied with 4 x Generators that are used to regulate both the air consumption and air temperature. The Yellow 10CFM, Red 15CFM, Blue 25CFM and Brown 35CFM Generators can be easily switched to suit different conditions or applications.

The Cooler can be mounted to the directly to the top, side or underneath of the enclosure via a 26mm diameter hole. An O-ring seal between the Cabinet Cooler and the enclosure wall maintains the integrity of the enclosure.

The Cabinet Cooler is available in both Stainless Steel grades 303 and 316L, allowing it to be used in a wide variety of applications. A Cabinet Cooler System is also available, this includes a digital thermostat and Solenoid valve and allows the cooler to automatically maintain a set temperature. This reduces compressed air and running costs.

Product Codes

Cabinet Cooler unit – IP66 Cabinet Cooler in SS303 – A70025-SS303

Cabinet Cooler System – A70025-SS303 with 24V Thermostat and Solenoid – A70325-SS303-24V

Cabinet Cooler System – A70025-SS303 with 240V Thermostat and Solenoid – A70325-SS303-240V

Cabinet Cooler System – A70025-SS303 with 110V Thermostat and Solenoid – A70325-SS303-110V

Cabinet Cooler unit – IP66 Cabinet Cooler in SS316L – A70025-SS316

Cabinet Cooler System – A70025-SS316L with 24V Thermostat and Solenoid – A70325-SS316-24V

Cabinet Cooler System – A70025-SS316L with 240V Thermostat and Solenoid – A70325-SS316-240V

Cabinet Cooler System – A70025-SS316L with 110V Thermostat and Solenoid – A70325-SS316-110V



Features & Benefits
Innovative Design Small Size allows installation into Small spaces
No Moving parts Reduced maintenance
Adjustable Supplied with 4 x Generators to control air volume and temperature.
Low noise 73dBA with red generator at 80 psi (5.4 Bar)
Cabinet Cooler System Available Cabinet Cooler system includes a Digital Thermostat and Solenoid. These will allow you to control compressed air usage and reduce running costs.
Prevents dust and ingress The Cabinet Cooler creates positive pressure inside cabinet to stop ingress
Cold Fraction 70% (2.5 Turns from closed)
EX version available For use in Hazardous locations
Can be easily fitted to an existing panel/cabinet Ideal replacement for fans that are more commonly used to cool cabinets

Technical Characteristics
Dimensions (mm) (H) 194mm x (W) 45mm
Noise Level 73dBA (@ 80, psi, 5.5 Bar), with a Red Generator fitted.
Cooling Capacity 190 Watt (560 Btu/hr) to 703 Watt (2,400 Bty/hr)
IP Rating IP66 (Test Certificate Number TRA055426CC01)
Maximum Inlet Air Pressure 80 psi (5.5 Bar)
Maximum Inlet Air Temperature 55°C
Metal Grade Available in either Stainless Steel grade 303 or 316L
Pressure Relif Valve Dependant on inlet pressure the cooler will vent air at between 1.5 & 3kPa (0.015 and 0.03 bar)
Thermal Endurance to heat test In accordance with IEC6079-0:2017. Specimen subjected to three climatic pre-conditioning tests

Energy Saving Safety Blowgun

Product Code: A45000

Energy Saving Safety Blowguns from Meech combine an ergonomic lightweight gun handle with the Meech Air Saver Nozzle.

The innovative nozzle design forces compressed air through an adjustable circular slot and then directs it at high velocity over the outside of the nozzle cone. The design amplifies the output airflow by entraining the ambient air at a 25:1 ratio.

Meech blowguns typically save up to 70% of compressed air usage compared to conventional types of blowgun whilst dramatically reducing noise levels.

  Download
Features & Benefits
Innovative Design

Giving 25:1 air amplification
No Moving Parts

Low maintenance
Adjustability

Application specific set-up. Leading to hundreds of different applications
Ergonomic Handle

Operator comfort
Lower Noise Levels

Up to 30dBA noise reduction – health and saftey compliant
Lower Compressed Air Usage

Lower running costs and in turn lower energy bills
Energy Saving

Can dramatically cut compressed air usage
Available in Aluminium or Stainless Steel

Suitable for a wide range of industries
Technical Characteristics
Dimensions (mm)

(H)150 x (L) 140
Images
Videos
Documentation

Meech Air Technology - Air Efficiency Range Brochure

Download

Energy Saving Safety Nozzles, Blow Guns, Air Amplifiers & High Thrust Jets Operating Manual

Download

A45400___Air_Saver_Blow_Gun_1

Download

Energy Saving Safety Blowgun

Product Code: A45000

Energy Saving Safety Blowguns from Meech combine an ergonomic lightweight gun handle with the Meech Air Saver Nozzle.

The innovative nozzle design forces compressed air through an adjustable circular slot and then directs it at high velocity over the outside of the nozzle cone. The design amplifies the output airflow by entraining the ambient air at a 25:1 ratio.

Meech blowguns typically save up to 70% of compressed air usage compared to conventional types of blowgun whilst dramatically reducing noise levels.



Features & Benefits
Innovative Design Giving 25:1 air amplification
No Moving Parts Low maintenance
Adjustability Application specific set-up. Leading to hundreds of different applications
Ergonomic Handle Operator comfort
Lower Noise Levels Up to 30dBA noise reduction - health and saftey compliant
Lower Compressed Air Usage Lower running costs and in turn lower energy bills
Energy Saving Can dramatically cut compressed air usage
Available in Aluminium or Stainless Steel Suitable for a wide range of industries

Technical Characteristics
Dimensions (mm) (H)150 x (L) 140

DC Splitters

Product Code: A2WAY / A4WAY / A8WAY / A9WAY

Meech offer a range of DC Splitters to complement our Pulsed DC Controllers. Our controllers are limited to powering up to 2 ionising products. Our Splitters give the Pulsed DC Controllers the versatility of distributing high voltage DC power from multiple ionisers to meet the demands of each job.

Available in 2 way, 4 way, 8 way and 9 way configurations, the Splitters are built with durable, high-quality fire retardant PVC to withstand demanding environments and comprise of 500mm of cable and a plug for connection to the controllers. They are fully compatible with Meech’s range of Pulsed DC Controllers and ionising equipment.

  Download
Technical Characteristics
Material

Fire retardant PVC.
Voltage Rating

Maximum 15kV DC.
Dimensions (Box)

2 WAY: 29mm x 58mm x 12 mm. 4 WAY: 44mm x 60mm x 12 mm. 8 WAY: 112mm x 58mm x 12mm. 9 WAY: 127mm x 58mm x 12mm (W x H x D) plus 0.5m of cable as standard.
Mounting

2 x M4 clearance holes provided.
Cable

0.5m of cable as standard.
Connection

Push-in plug.
Must Haves
PulseDrive Plus PDC Controller PulseDrive Plus PDC Controller

Product Code: APD15-PLUS-00

View Product
PulseDrive Lite PDC Controller PulseDrive Lite PDC Controller

Product Code: APD15-LITE-00

View Product
PulseDrive Plus HL 5.5kV PDC Controller PulseDrive Plus HL 5.5kV PDC Controller

Product Code: APD-HL5.5KV-PLUS-00

View Product
PulseDrive Plus HL 9.0kV PDC Controller

Product Code: APD-HL9.0KV-PLUS-00

View Product

DC Splitters

Product Code: A2WAY / A4WAY / A8WAY / A9WAY

Meech offer a range of DC Splitters to complement our Pulsed DC Controllers. Our controllers are limited to powering up to 2 ionising products. Our Splitters give the Pulsed DC Controllers the versatility of distributing high voltage DC power from multiple ionisers to meet the demands of each job.

Available in 2 way, 4 way, 8 way and 9 way configurations, the Splitters are built with durable, high-quality fire retardant PVC to withstand demanding environments and comprise of 500mm of cable and a plug for connection to the controllers. They are fully compatible with Meech’s range of Pulsed DC Controllers and ionising equipment.



Technical Characteristics
Material Fire retardant PVC.
Voltage Rating Maximum 15kV DC.
Dimensions (Box) 2 WAY: 29mm x 58mm x 12 mm. 4 WAY: 44mm x 60mm x 12 mm. 8 WAY: 112mm x 58mm x 12mm. 9 WAY: 127mm x 58mm x 12mm (W x H x D) plus 0.5m of cable as standard.
Mounting 2 x M4 clearance holes provided.
Cable 0.5m of cable as standard.
Connection Push-in plug.

Energy Saving Safety Nozzle

Product Code: A48000

Energy Saving Safety Nozzles from Meech can save up to 70% of compressed air demand whilst dramatically reducing noise levels.

The innovative nozzle design forces compressed air through an adjustable circular slot and then directs it at high velocity over the outside of the nozzle cone.

The design amplifies the output airflow by entraining the ambient air at a 25:1 ratio.

  Download
Features & Benefits
Innovative Design

Giving 25:1 air amplification
Adjustability

Application specific set-up. Leading to hundreds of different applications
Lower Noise Levels

Dramatic reduction of noise levels compared to “open pipe” – compliant with health and saftey requirements
Lower Compressed Air Usage

Lower running costs and in turn lower energy bills
Energy Saving

Can dramatically cut compressed air usage
Compatible with Meech Blowgun

Opening up even more uses
Available in Aluminium and Stainless Steel

Suitable for a wide range of industries
Technical Characteristics
Dimensions (mm)

(H)21, (L)49
Images
Videos
Documentation

Meech Air Technology - Air Efficiency Range Brochure

Download

Energy Saving Safety Nozzles, Blow Guns, Air Amplifiers & High Thrust Jets Operating Manual

Download

Energy Saving Safety Nozzle

Product Code: A48000

Energy Saving Safety Nozzles from Meech can save up to 70% of compressed air demand whilst dramatically reducing noise levels.

The innovative nozzle design forces compressed air through an adjustable circular slot and then directs it at high velocity over the outside of the nozzle cone.

The design amplifies the output airflow by entraining the ambient air at a 25:1 ratio.



Features & Benefits
Innovative Design Giving 25:1 air amplification
Adjustability Application specific set-up. Leading to hundreds of different applications
Lower Noise Levels Dramatic reduction of noise levels compared to "open pipe" - compliant with health and saftey requirements
Lower Compressed Air Usage Lower running costs and in turn lower energy bills
Energy Saving Can dramatically cut compressed air usage
Compatible with Meech Blowgun Opening up even more uses
Available in Aluminium and Stainless Steel Suitable for a wide range of industries

Technical Characteristics
Dimensions (mm) (H)21, (L)49

Coldstream Air Gun

Product Code: A60000

Coldstream Air Guns from Meech Air Technology provide a cold airflow that is commonly used for spot cooling.

The Vortex Tube is at the heart of the Coldstream Gun, encased within hot and cold end silencers. The cold air produced by the Vortex Tube is easily directed on to the area to be cooled via the knuckle trunking. The hot air created by the opposite end of the Vortex Tube flows into the atmosphere via a silencer.

The cold airflow can be as low as 50°C below the inlet air temperature and be maintained to +/- 0.6°C.

The attached drawing on the data sheet is for a Large ColdStream Air Gun.

  Download
Features & Benefits
No Moving Parts

Low maintenance and easy to use
Stainless Steel

Suitable for harsh environments
Adjustment Knob (adjustable models only)

Accurate temperature control
28cm Knuckle Trunking

Easy direction of cold airflow
Magnetic Base

Quick and easy mounting to any metallic surface and can be moved with little hassel.
Available in 2 Sizes

Large Coldstream Gun and small Coldstream Gun available
Technical Characteristics
Dimensions (mm)

Adjustable Large – (L) 280mm x (H) 44.5mm

Non-Adjustable Large – (L) 258mm x (H) 44.5mm
Images
Videos
Documentation

Meech Air Technology - Vortex Cooling Range Brochure

Download

Coldstream Air Gun, Adjustable Coldstream Air Gun & Small Coldstream Air Gun Operating Manual

Download

Large_Cold_Stream_Air_Gun

Download
Related Products
Small Coldstream Air Gun

Product Code: A60008

The Small Coldstream Air Gun is specially designed for smaller, more delicate applications that require less air flow.

View Product

Coldstream Air Gun

Product Code: A60000

Coldstream Air Guns from Meech Air Technology provide a cold airflow that is commonly used for spot cooling.

The Vortex Tube is at the heart of the Coldstream Gun, encased within hot and cold end silencers. The cold air produced by the Vortex Tube is easily directed on to the area to be cooled via the knuckle trunking. The hot air created by the opposite end of the Vortex Tube flows into the atmosphere via a silencer.

The cold airflow can be as low as 50°C below the inlet air temperature and be maintained to +/- 0.6°C.

The attached drawing on the data sheet is for a Large ColdStream Air Gun.



Features & Benefits
No Moving Parts Low maintenance and easy to use
Stainless Steel Suitable for harsh environments
Adjustment Knob (adjustable models only) Accurate temperature control
28cm Knuckle Trunking Easy direction of cold airflow
Magnetic Base Quick and easy mounting to any metallic surface and can be moved with little hassel.
Available in 2 Sizes Large Coldstream Gun and small Coldstream Gun available

Technical Characteristics
Dimensions (mm) Adjustable Large - (L) 280mm x (H) 44.5mm Non-Adjustable Large - (L) 258mm x (H) 44.5mm

Energy Saving Air Amplifiers

Product Code: A15000

Meech Air Technology Energy Saving Air Amplifiers provide large airflows whilst only consuming a minimal volume of compressed air.

A tiny amount of compressed air is released through an adjustable circular slot inside the Air Amplifier creating a ‘tube’ of air. The ‘tube’ of air then travels towards the front creating areas of low pressure behind and in front that entrains ambient air at a ratio of between 4 and 25:1 depending on the size of air amplifier.

Meech Air Amplifiers are available in five sizes in aluminium (three sizes available in stainless steel) to suit a wide range of applications.

For more information or for sales enquiries please contact us.

  Download
Features & Benefits
Innovative Design

Giving air amplification ranging from 4 to 25:1
No Moving Parts

Low maintenance
Adjustability

Application specific set-up (no shims). Leading to hundreds of different applications
Locking Ring

Holds specific set-up
Lower Noise Levels

Up to 50dBA noise reduction compared to ‘open pipe’ systems – Health and Safety Compliant
Available in 5 Sizes

From 18mm to 100mm air outlet
Available in Aluminium or Stainless Steel

Suitable for a wide range of industries
Lower Compressed Air Usage

Lower running costs and in turn lower energy bills
Technical Characteristics
Dimensions

A15005 – Extra Small – 44mm (L) x 28mm (H) x 12mm throat (18mm outlet)
A15008 – Small – 73mm (L) x 50mm (H) x 20mm throat (32mm outlet)
A15006 – Medium – 90mm (L) x 60mm (H) x 25mm throat (37mm outlet)
A15015 – Large – 84mm (L) x 76mm (H) x 40mm throat (51mm outlet)
A15030 – Extra Large – 128mm (L) x 127mm (H) x 74mm throat (100mm outlet)
Images
Videos
Documentation

Meech Air Technology - Air Efficiency Range Brochure

Download

Energy Saving Safety Nozzles, Blow Guns, Air Amplifiers & High Thrust Jets Operating Manual

Download
Related Products
Energy Saving High Thrust Jet

Product Code: A38000

Meech Air Technology High Thrust Jets provide a high power blast of air whilst reducing compressor demand and lowering noise levels.

View Product
Energy Saving Safety Nozzle

Product Code: A48000

Energy Saving Safety Nozzles from Meech can save up to 70% of compressed air demand whilst dramatically reducing noise levels.

View Product
Energy Saving Air Curtain

Product Code: A85000

Meech Air Curtains provide an efficient blade of compressed air for wide area blow-off and air drying applications.

View Product

Energy Saving Air Amplifiers

Product Code: A15000

Meech Air Technology Energy Saving Air Amplifiers provide large airflows whilst only consuming a minimal volume of compressed air.

A tiny amount of compressed air is released through an adjustable circular slot inside the Air Amplifier creating a ‘tube’ of air. The ‘tube’ of air then travels towards the front creating areas of low pressure behind and in front that entrains ambient air at a ratio of between 4 and 25:1 depending on the size of air amplifier.

Meech Air Amplifiers are available in five sizes in aluminium (three sizes available in stainless steel) to suit a wide range of applications.

For more information or for sales enquiries please contact us.



Features & Benefits
Innovative Design Giving air amplification ranging from 4 to 25:1
No Moving Parts Low maintenance
Adjustability Application specific set-up (no shims). Leading to hundreds of different applications
Locking Ring Holds specific set-up
Lower Noise Levels Up to 50dBA noise reduction compared to 'open pipe' systems - Health and Safety Compliant
Available in 5 Sizes From 18mm to 100mm air outlet
Available in Aluminium or Stainless Steel Suitable for a wide range of industries
Lower Compressed Air Usage Lower running costs and in turn lower energy bills

Technical Characteristics
Dimensions A15005 - Extra Small – 44mm (L) x 28mm (H) x 12mm throat (18mm outlet)  A15008 - Small – 73mm (L) x 50mm (H) x 20mm throat (32mm outlet)  A15006 - Medium – 90mm (L) x 60mm (H) x 25mm throat (37mm outlet)  A15015 - Large – 84mm (L) x 76mm (H) x 40mm throat (51mm outlet)  A15030 - Extra Large – 128mm (L) x 127mm (H) x 74mm throat (100mm outlet)

Energy Saving High Thrust Jet

Product Code: A38000

Meech Air Technology High Thrust Jets are designed to provide a high power blast of air whilst reducing compressor demand and lowering noise levels.

The High Thrust Jets use a very small amount of compressed air to generate a high power blow off force. This is achieved by forcing compressed air through an adjustable internal circular slot.

The high velocity air from the slot generates an area of low pressure at the rear of the jet that entrains ambient air at a ratio of 4:1. This maximises the high power blow off.

  Download
Features & Benefits
Innovative Design

Giving up to 4:1 air amplification
No Moving Parts

Low maintenance
Adjustability

Application specific set-up (no shims). Leading to hundreds of different applications
Lower Noise Levels

Up to 50dBA noise reduction – Health and Saftey compliant
Lower Compressed Air Usage

Lower running costs and in turn lower energy bills
Energy Saving

Can dramatically cut compressed air usage
In-line High Thrust Jet version available

Ideal for for retrofitting open air line blow-off applications where system set-up does not change frequently. It is also perfect to convey fine granular products.
Images
Videos
Documentation

Meech Air Technology - Air Efficiency Range Brochure

Download

Energy Saving Safety Nozzles, Blow Guns, Air Amplifiers & High Thrust Jets Operating Manual

Download
Related Products
Energy Saving Air Amplifiers

Product Code: A15000

Meech Air Technology Energy Saving Air Amplifiers provide large airflows whilst only consuming a minimal volume of compressed air.

View Product

Energy Saving High Thrust Jet

Product Code: A38000

Meech Air Technology High Thrust Jets are designed to provide a high power blast of air whilst reducing compressor demand and lowering noise levels.

The High Thrust Jets use a very small amount of compressed air to generate a high power blow off force. This is achieved by forcing compressed air through an adjustable internal circular slot.

The high velocity air from the slot generates an area of low pressure at the rear of the jet that entrains ambient air at a ratio of 4:1. This maximises the high power blow off.



Features & Benefits
Innovative Design Giving up to 4:1 air amplification
No Moving Parts Low maintenance
Adjustability Application specific set-up (no shims). Leading to hundreds of different applications
Lower Noise Levels Up to 50dBA noise reduction - Health and Saftey compliant
Lower Compressed Air Usage Lower running costs and in turn lower energy bills
Energy Saving Can dramatically cut compressed air usage
In-line High Thrust Jet version available Ideal for for retrofitting open air line blow-off applications where system set-up does not change frequently. It is also perfect to convey fine granular products.

Vortex Tube

Product Code: A20000

Meech Stainless Steel Vortex Tubes convert compressed air into two airflows, one extremely cold and the other extremely hot.

Compressed air enters the spin chamber tangentially. This causes the column of air inside the tube to rotate at very high speed (up to 1 million rpm). The air at the outside of the column, moving very fast has a lot of energy and is hot. The air at the centre of the column, moving relatively slowly has little energy and is cold. The hot outer air is bled off at one end of the tube and the cold inner air at the other.

Vortex Tubes have no moving parts and can produce temperatures as low as 50°C below the inlet air temperature and as high as 110°C.

The attached drawing on the data sheet is for a medium vortex tube.

  Download
Features & Benefits
Innovative Design

Temperature drop as low as 50ºC below inlet air temp. Hot air up to +110ºC
Stainless Steel

Hard wearing and hygienic
No Moving Parts

Virtually no maintenance
Relief Valve

Accurate temperature control
Available in 2 Sizes

Medium Vortex Tube (10 – 35cfm) and Small Vortex Tube (8cfm). Suitable for a wide range of applications
Technical Characteristics
Dimensions (mm)

Medium  (L) 212.3mm x (H) 44.5mm
Images
Videos
Documentation

Meech Air Technology - Vortex Cooling Range Brochure

Download

Medium_Vortex_Tube

Download
Related Products
Small Vortex Tube

Product Code: A21000

Meech Small Vortex Tube converts compressed air into two airflows, one as low as 50°C below the inlet air temperature and one as high as 50°C above.

View Product

Vortex Tube

Product Code: A20000

Meech Stainless Steel Vortex Tubes convert compressed air into two airflows, one extremely cold and the other extremely hot.

Compressed air enters the spin chamber tangentially. This causes the column of air inside the tube to rotate at very high speed (up to 1 million rpm). The air at the outside of the column, moving very fast has a lot of energy and is hot. The air at the centre of the column, moving relatively slowly has little energy and is cold. The hot outer air is bled off at one end of the tube and the cold inner air at the other.

Vortex Tubes have no moving parts and can produce temperatures as low as 50°C below the inlet air temperature and as high as 110°C.

The attached drawing on the data sheet is for a medium vortex tube.



Features & Benefits
Innovative Design Temperature drop as low as 50ºC below inlet air temp. Hot air up to +110ºC
Stainless Steel Hard wearing and hygienic
No Moving Parts Virtually no maintenance
Relief Valve Accurate temperature control
Available in 2 Sizes Medium Vortex Tube (10 - 35cfm) and Small Vortex Tube (8cfm). Suitable for a wide range of applications

Technical Characteristics
Dimensions (mm) Medium  (L) 212.3mm x (H) 44.5mm

251 Ion Gun

Product Code: A251

Meech’s Model 251 Ion Gun is a robust, lightweight injection moulded product for use with the Meech PulseDrive Pulsed DC Controller.

It is suitable for contamination blow-off and neutralisation of static charges in electronic applications and cleanroom environments. It is quick, easy and safe to use. Supplied with 2 metres of cable as standard.

  Download
Technical Characteristics
Weight

0.16 kg
Operating Voltage

8 kV DC nominal
Emitters

Machined titanium (replaceable)
Length

190 mm
Max Pressure

Not to be used above 7 bar (100 psi)
Recommended pressure 1.5 – 4 bar
(20 – 60 psi)
Body

FR ABS
Ozone

Less than 0.01 ppm
Ion Balance

+/- 10 V at set up
Noise Level (1m)

72 dBA at 1.5 bar (20 psi)
Decay time (1000v - 100v) 150mm

Typically less than 0.5 secs
Images
Documentation

Meech Static Control Brochure

Download
Related Products
Test Kit – 983v2 & 984v2

Product Code: 983V2-984V2-KIT

The 983v2 & 984v2 test kit allows diagnosis of static related issues and ionising equipment performance monitoring.

View Product
Must Haves
PulseDrive Lite PDC Controller PulseDrive Lite PDC Controller

Product Code: APD15-LITE-00

View Product
PulseDrive Plus PDC Controller PulseDrive Plus PDC Controller

Product Code: APD15-PLUS-00

View Product

251 Ion Gun

Product Code: A251

Meech’s Model 251 Ion Gun is a robust, lightweight injection moulded product for use with the Meech PulseDrive Pulsed DC Controller.

It is suitable for contamination blow-off and neutralisation of static charges in electronic applications and cleanroom environments. It is quick, easy and safe to use. Supplied with 2 metres of cable as standard.



Technical Characteristics
Weight 0.16 kg
Operating Voltage 8 kV DC nominal
Emitters Machined titanium (replaceable)
Length 190 mm
Max Pressure Not to be used above 7 bar (100 psi) Recommended pressure 1.5 - 4 bar (20 - 60 psi)
Body FR ABS
Ozone Less than 0.01 ppm
Ion Balance +/- 10 V at set up
Noise Level (1m) 72 dBA at 1.5 bar (20 psi)
Decay time (1000v - 100v) 150mm Typically less than 0.5 secs

993R Spark Free Generator Bar

Product Code: 993R

The Meech Model 993R is a high performance generator bar for use with the Meech range of 30kV and 50kV high voltage DC static generators.

Resistively coupled emitter pins deliver smooth, controlled pinning whilst spark free operation avoids tripping out on intermittent applications.

  Download
Features & Benefits
Resistively Coupled Emitter Pins

Power is delivered in a smooth, controlled manner. Spark free operation. Eliminates incidences of flash over often experienced with bars directly coupled to the high voltage supply. Greatly improved operator safety.
Technical Characteristics
Weight

Approx. 400g per metre length.
Dimensions

24mm x 44mm x length (Up to 3000mm)
Operating Voltage

Up to 50kVDC
Cable

2 metres shielded in flexible conduit: longer
lengths can be ordered
Construction

PVC extrusion, titanium emitter pins
Mounting

Two M10 x 50mm nylon studs
Maximum Temperature

60ºC
Operating Current

0.5mA max
Polarity

Either positive or negative
Applications
Images
Documentation

Meech Static Control Brochure

Download

A993R_Assembly

Download

993R Operating Manual

Download
Related Products
995 Claw Style Edge Pinning

Product Code: A995-CLAW-1

The 995 Edge Pinning Claw is a powerful pinning head intended for use on cast-film lines

View Product
995 Pinning Head

Product Code: A995R-XXXX

The 995 range of Pinning Heads have been designed for use with all Meech static generators and can be operated at up to 50kV.

View Product
Must Haves
Hyperion IonCharge30 (15W)

Product Code: AIC30-15DC

The Meech IonCharge 30 uses advanced high voltage technology and software for a controlled static charge via our range of static generator bars and pinning heads.

View Product
Hyperion IonCharge50 (75W)

Product Code: AIC50-75DC

IonCharge50 – 75W static generator is designed for a range of applications. It uses advanced high voltage technology and software for a controlled static charge via our range of static generator bars and pinning heads.

View Product
Switchmode Power Adaptor 100W Switchmode Power Adaptor 100W

Product Code: A900IPS-SM-96W-XX

A general 24V DC 45W Power Adaptor.

View Product
Switchmode Power Adaptor 48W

Product Code: A900IPS-SM-48W-XX

A 24V DC 48W Power Adaptor for use with certain products within the Meech range.

View Product

993R Spark Free Generator Bar

Product Code: 993R

The Meech Model 993R is a high performance generator bar for use with the Meech range of 30kV and 50kV high voltage DC static generators.

Resistively coupled emitter pins deliver smooth, controlled pinning whilst spark free operation avoids tripping out on intermittent applications.



Features & Benefits
Resistively Coupled Emitter Pins Power is delivered in a smooth, controlled manner. Spark free operation. Eliminates incidences of flash over often experienced with bars directly coupled to the high voltage supply. Greatly improved operator safety.

Technical Characteristics
Weight Approx. 400g per metre length.
Dimensions 24mm x 44mm x length (Up to 3000mm)
Operating Voltage Up to 50kVDC
Cable 2 metres shielded in flexible conduit: longer lengths can be ordered
Construction PVC extrusion, titanium emitter pins
Mounting Two M10 x 50mm nylon studs
Maximum Temperature 60ºC
Operating Current 0.5mA max
Polarity Either positive or negative

915-WRES Water Resistant Coating

Product Code: 915-WRES

A water resistant option allows the installation of bars where routine machine cleaning can cause them to be splashed.

This option is suitable for the model 915 shockless bar.

  Download
Images
Related Products
915-Dust – Dust Proof Coating

Product Code: A915-DUST

For installation in dirty or dusty environments, the dust proof option improves reliance of the bar.

View Product
Test Kit – 983v2 & 984v2

Product Code: 983V2-984V2-KIT

The 983v2 & 984v2 test kit allows diagnosis of static related issues and ionising equipment performance monitoring.

View Product
Must Haves
915 Anti-Static Bar

Product Code: A915-XXXX

Fast and powerful static control for high-speed applications with effective ionisation up to distances of 150mm.

View Product

915-WRES Water Resistant Coating

Product Code: 915-WRES

A water resistant option allows the installation of bars where routine machine cleaning can cause them to be splashed.

This option is suitable for the model 915 shockless bar.



900-HTCON In-line Connector For AC Bars

Product Code: 900-HTCON

On machinery where AC bars need to be disconnected periodically, the quick connect options provides a simple solution.

The connector can be used to provide a quick disconnect system for ionising bars or can be used to overcome problematic bar installations where machine bulk heads make cable routing difficult.

  Download
Features & Benefits
Aluminium body

Provides mechanical and electrical protection
Technical Characteristics
Dimensions

110mm x 25mm
Operating voltage

Maximum 7KV ac
Construction

Aluminium/PEEK
Images
Related Products
Test Kit – 983v2 & 984v2

Product Code: 983V2-984V2-KIT

The 983v2 & 984v2 test kit allows diagnosis of static related issues and ionising equipment performance monitoring.

View Product
Must Haves
915 Anti-Static Bar

Product Code: A915-XXXX

Fast and powerful static control for high-speed applications with effective ionisation up to distances of 150mm.

View Product
914 Ionising Bar 914 Short-Range Ionising Bar

Product Code: A914-XXXX

View Product

900-HTCON In-line Connector For AC Bars

Product Code: 900-HTCON

On machinery where AC bars need to be disconnected periodically, the quick connect options provides a simple solution.

The connector can be used to provide a quick disconnect system for ionising bars or can be used to overcome problematic bar installations where machine bulk heads make cable routing difficult.



Features & Benefits
Aluminium body Provides mechanical and electrical protection

Technical Characteristics
Dimensions 110mm x 25mm
Operating voltage Maximum 7KV ac
Construction Aluminium/PEEK

990SRM Surface Resistance Meter

Product Code: 990SRM

The Model 990SRM is a convenient, pocket-sized meter for measurement of surface resistivity and resistance to ground.

The 990SRM has a measurement range of 103 to 1012 Ohms per square and an accuracy of ± ½ Decade. It is a useful tool for testing materials for static charging applications and for diagnosing static electricity related problems.

  Download
Technical Characteristics
Power

9 volt battery
Dimensions

96mm x 61mm x 26mm
Weight

170g
Accuracy

± 10%
Battery life

Over 40 hours of continuous use
Display

LED’s – one per decade
Images
Documentation

Meech Static Control Brochure

Download

990 SRM Operator Manual

Download

990SRM Technical Drawing

Download

990SRM Surface Resistance Meter

Product Code: 990SRM

The Model 990SRM is a convenient, pocket-sized meter for measurement of surface resistivity and resistance to ground.

The 990SRM has a measurement range of 103 to 1012 Ohms per square and an accuracy of ± ½ Decade. It is a useful tool for testing materials for static charging applications and for diagnosing static electricity related problems.



Technical Characteristics
Power 9 volt battery
Dimensions 96mm x 61mm x 26mm
Weight 170g
Accuracy ± 10%
Battery life Over 40 hours of continuous use
Display LED's - one per decade
